Third party certified for IEC 61000-4-30 Class A Ed. 3
Number of Channels:
Number of Current Inputs : 4
Number of Voltage Channel : 4
Multi-Gain™ Sensing Provides Highly Accurate Measurements over a Wide Dynamic Range Typical .Accuracy remain stable over wide temperature range
Memory: As high as 1200 MB for long storage of data. This help to retrieve information in case of communication failure.
Integrated display, Colour touchscreen
Advance communications available-Programmable parity and stop bits, Communication protocols: Modbus, TCP/IP, ASCII/RTU; DNP3; IEC 61850 ,SNMP, USB 1.1/2.0 Virtual COM port, RJ45 Ethernet port 10/100BaseT, Optional 2nd Ethernet port – RJ45 or Fiber Optic 2 RS485 ports
Simultaneously Operating Communication Ports
6 digital Inputs & 2 digital out puts available
VAUX Input helps neutral to ground or aux voltage readings for synchronizing schemes, for example, obtain the frequency, magnitude and phase angle on both sides of a switch or between generator and bus voltage.
Pick up range starts as low as 1 mA and high accuracy is attained at 25 mA.
Extensive logging as high as 8 logs of programmable historical profiles. Each log can record 64 parameters
Built-in CORE™ log provides pre-configured, automatic logging of most metering parameters
Load aggregation/universal metering: aggregate or accumulate different loads with pulse inputs. Utility commodities such as gas and water can also be accumulated
Power quality log ITIC CBEMA Curve and SEMI F47 standards
Measure power quality indices such as voltage anomalies, harmonics, flicker, imbalances
Facilitate forensic engineering analysis of harmful events in your power system with the meter’s micro-second resolution recording of sag/swell waveform events, including peak and duration of the event.
View harmonic magnitudes to the 511th order for each voltage and current channel. Harmonic magnitudes and phase angles in real time are resolved to the 127th order. Conduct power quality analysis at the high end of the harmonic magnitude spectrum.
The meter calculates weekly EN 50160 power quality reports. Determine power system reliability with these reports, which can be easily accessed from the meter’s web server
Resilient Cyber Security™ Protects Meter from Tampering Highly Secure, 32 Complex Character Passwords with 128-bit AES Encryption & Password Fail Timeouts Virtually Eliminate Brute Force Hacking.
Physical Seals and Sealing Switch Prevent Remote Hacking or Tampering.
